Noises Off Light Plot PDF Format
Noises Off Light Plot AutoCAD DWG
Noises Off Channel Hookup Excel Format
Focus Areas
Channel Hookup
| Position | Unit# | Focus | Color | Chan# | Dim# | Type | Lamp |
| MIDCAT | 2 | FP1 | NC | 1 | S4 PAR | 575 | |
| MIDCAT | 7 | FP2 | NC | 2 | S4 PAR | 575 | |
| MIDCAT | 12 | FP3 | NC | 3 | S4 PAR | 575 | |
| MIDCAT | 16 | FP4 | NC | 4 | S4 PAR | 575 | |
| MIDCAT | 22 | FP5 | NC | 5 | S4 PAR | 575 | |
| MIDCAT | 26 | FP6 | NC | 6 | S4 PAR | 575 | |
| MIDCAT | 3 | FP7 | NC | 7 | S4 PAR | 575 | |
| MIDCAT | 8 | FP8 | NC | 8 | S4 PAR | 575 | |
| MIDCAT | 13 | FP9 | NC | 9 | S4 PAR | 575 | |
| MIDCAT | 21 | FP10 | NC | 10 | S4 PAR | 2 | |
| MIDCAT | 27 | FP11 | NC | 11 | S4 PAR | 575 | |
| SL UPPER TECH B | 1 | FP12 | NC | 12 | S4 26° | 575 | |
| SR UPPER TECH B | 6 | FP12 | NC | 13 | S4 19° | 575 | |
| SL UPPER TECH B | 4 | FP13 | NC | 14 | S4 26° | 575 | |
| SR UPPER TECH B | 4 | FP13 | NC | 15 | S4 26° | 575 | |
| SL UPPER TECH B | 6 | FP14 | NC | 16 | S4 19° | 575 | |
| SR UPPER TECH B | 1 | FP14 | NC | 17 | S4 26° | 575 | |
| MIDCAT | 1 | FP1 | NC | 21 | S4 26° | 575 | |
| MIDCAT | 4 | FP7 | NC | 21 | S4 26° | 575 | |
| MIDCAT | 9 | FP2 | NC | 22 | S4 26° | 575 | |
| MIDCAT | 11 | FP8 | NC | 23 | S4 26° | 575 | |
| MIDCAT | 14 | FP3 | NC | 23 | S4 26° | 575 | |
| MIDCAT | 15 | FP9 | NC | 24 | S4 26° | 575 | |
| MIDCAT | 18 | FP4 | NC | 24 | S4 26° | 575 | |
| MIDCAT | 25 | FP6 | NC | 26 | S4 26° | 575 | |
| MIDCAT | 28 | FP11 | NC | 26 | S4 26° | 575 | |
| MIDCAT | 20 | FP10 | NC | 30 | S4 26° | 575 | |
| MIDCAT | 10 | TBD | NC | 31 | S4 19° | 575 | |
| SL UPPER TECH B | 7 | FP14 | NC | 32 | S4 19° | 575 | |
| SL UPPER TECH B | 5 | FP13 | NC | 32 | S4 26° | 575 | |
| SL UPPER TECH B | 3 | FP12 | NC | 32 | S4 26° | 575 | |
| SR UPPER TECH B | 7 | FP12 | NC | 33 | S4 19° | 575 | |
| SR UPPER TECH B | 5 | FP13 | NC | 33 | S4 26° | 575 | |
| SR UPPER TECH B | 3 | FP14 | NC | 33 | S4 26° | 575 | |
| NEAR CAT | 3 | HR STEPS | R79 | 40 | S4 PAR | 575 | |
| 1ST ELECTRIC | 6 | FP1 | R79 | 41 | S4 PAR | 575 | |
| NEAR CAT | 4 | FP2 | R79 | 42 | S4 PAR | 575 | |
| NEAR CAT | 8 | FP3 | R79 | 43 | S4 PAR | 575 | |
| NEAR CAT | 9 | FP4 | R79 | 44 | S4 PAR | 575 | |
| NEAR CAT | 13 | FP5 | R79 | 45 | S4 PAR | 575 | |
| 1ST ELECTRIC | 23 | FP6 | R79 | 46 | S4 PAR | 575 | |
| 2ND ELECTRIC | 6 | FP7 | R79 | 47 | S4 PAR | 575 | |
| 1ST ELECTRIC | 8 | FP8 | R79 | 48 | S4 PAR | 575 | |
| 1ST ELECTRIC | 13 | FP9 | R79 | 49 | S4 PAR | 575 | |
| 1ST ELECTRIC | 21 | FP10 | R79 | 50 | S4 PAR | 575 | |
| 2ND ELECTRIC | 22 | FP11 | R79 | 51 | LED COIDAK | LED | |
| 2ND ELECTRIC | 13 | FP12 | R79 | 52 | S4 PAR | 575 | |
| 2ND ELECTRIC | 15 | FP13 | R79 | 53 | LED COIDAK | LED | |
| 2ND ELECTRIC | 16 | FP14 | R79 | 54 | S4 PAR | 575 | |
| NEAR CAT | 14 | HL STEPS | R79 | 55 | S4 PAR | 575 | |
| 1ST ELECTRIC | 4 | FP1 | R39 | 61 | S4 36° | 575 | |
| 1ST ELECTRIC | 5 | FP2 | R39 | 62 | S4 36° | 575 | |
| 1ST ELECTRIC | 12 | FP3 | R39 | 63 | S4 36° | 575 | |
| 1ST ELECTRIC | 18 | FP4 | R39 | 64 | S4 36° | 575 | |
| 1ST ELECTRIC | 20 | FP5 | R39 | 65 | S4 26° | 575 | |
| 1ST ELECTRIC | 25 | FP6 | R39 | 66 | S4 36° | 575 | |
| 7 | FP7 | R39 | 67 | LED | |||
| 1ST ELECTRIC | 9 | FP8 | R39 | 68 | S4 26° | 575 | |
| 1ST ELECTRIC | 17 | FP9 | R39 | 69 | S4 36° | 575 | |
| 1ST ELECTRIC | 19 | FP10 | R39 | 70 | S4 36° | 575 | |
| 2ND ELECTRIC | 23 | FP11 | R39 | 71 | S4 PAR | 575 | |
| 2ND ELECTRIC | 8 | FP12 | R39 | 72 | S4 PAR | 575 | |
| 1ST ELECTRIC | 15 | FP13 | R39 | 73 | S4 PAR | 575 | |
| 2ND ELECTRIC | 21 | FP14 | R39 | 74 | S4 PAR | 575 | |
| SL LOWER TECH B | 1 | WALLS | NC | 81 | S4 36° | 575 | |
| SL LOWER TECH B | 3 | WALLS | NC | 82 | S4 26° | 575 | |
| SL LOWER TECH B | 5 | WALLS | NC | 83 | S4 19° | 575 | |
| SR LOWER TECH B | 1 | WALLS | NC | 84 | S4 36° | 575 | |
| SR LOWER TECH B | 3 | WALLS | NC | 85 | S4 26° | 575 | |
| SR LOWER TECH B | 5 | WALLS | NC | 86 | S4 19° | 575 | |
| SL LOWER TECH B | 6 | WALLS | R68 | 88 | S4 19° | 575 | |
| SL LOWER TECH B | 4 | WALLS | R68 | 88 | S4 26° | 575 | |
| SL LOWER TECH B | 2 | WALLS | R68 | 88 | S4 36° | 575 | |
| SR LOWER TECH B | 6 | WALLS | R68 | 89 | S4 19° | 575 | |
| SR LOWER TECH B | 4 | WALLS | R68 | 89 | Source Four 26° | 575 | |
| SR LOWER TECH B | 2 | WALLS | R68 | 89 | Source Four 36° | 575 | |
| NEAR CAT | 1 | FP1 | NC | 91 | Source Four 26° | 575 | |
| NEAR CAT | 2 | FP2 | NC | 91 | Source Four 26° | 575 | |
| NEAR CAT | 6 | FP8 | NC | 92 | Source Four 26° | 575 | |
| NEAR CAT | 7 | FP3 | NC | 92 | Source Four 26° | 575 | |
| NEAR CAT | 10 | FP4 | NC | 93 | Source Four 26° | 575 | |
| NEAR CAT | 11 | FP10 | NC | 93 | Source Four 26° | 575 | |
| NEAR CAT | 15 | FP5 | NC | 94 | Source Four 26° | 575 | |
| NEAR CAT | 16 | FP6 | NC | 94 | Source Four 26° | 575 | |
| 1ST ELECTRIC | 14 | FP9 | NC | 95 | Source Four 26° | 575 | |
| FOH PIPES | 1 | MOVER | N/A | 98 | Lonestar | 575HID | |
| FOH PIPES | 2 | MOVER | N/A | 99 | Lonestar | 575HID | |
| MIDCAT | 6 | TBD | TBD | 101 | Source Four 10° | 575 | |
| MIDCAT | 23 | TBD | TBD | 102 | Source Four 10° | 575 | |
| MIDCAT | 17 | TBD | TBD | 103 | S4 PAR | 575 | |
| SL LOWER TECH B | 1 | TBD | TBD | 104 | Source Four 26° | 575 | |
| SL UPPER TECH B | 2 | TBD | TBD | 105 | Source Four 26° | 575 | |
| SR LOWER TECH B | 1 | TBD | TBD | 106 | Source Four 26° | 575 | |
| SR UPPER TECH B | 2 | TBD | TBD | 107 | Source Four 26° | 575 | |
| NEAR CAT | 5 | TBD | TBD | 108 | Source Four 26° | 575 | |
| NEAR CAT | 12 | TBD | TBD | 109 | Source Four 26° | 575 | |
| LINESET 5 | 1 | 111 | CHANDELIER | ||||
| LINESET 5 | 2 | 112 | CHANDELIER | ||||
| LINESET 28 | 1 | CYC | LED | 121 | CYC LIGHT | 1K | |
| LINESET 28 | 2 | CYC | LED | 122 | CYC LIGHT | 1K | |
| LINESET 28 | 3 | CYC | LED | 123 | CYC LIGHT | 1K | |
| LINESET 28 | 4 | CYC | LED | 124 | CYC LIGHT | 1K | |
| LINESET 28 | 5 | CYC | LED | 125 | CYC LIGHT | 1K | |
| LINESET 28 | 6 | CYC | LED | 126 | CYC LIGHT | 1K | |
| LINESET 28 | 7 | CYC | LED | 127 | CYC LIGHT | 1K | |
| LINESET 28 | 8 | CYC | LED | 128 | CYC LIGHT | 1K | |
| LINESET 28 | 9 | CYC | LED | 129 | CYC LIGHT | 1K | |
| LINESET 28 | 10 | CYC | LED | 130 | CYC LIGHT | 1K | |
| MIDCAT | 19 | unused | Source Four 19° | 575 | |||
| 1ST ELECTRIC | 24 | unused | Source Four 36° | 575 | |||
| MIDCAT | 5 | unused | Source Four 19° | 575 | |||
| MIDCAT | 24 | unused | Source Four 19° | 575 | |||
| 1ST ELECTRIC | 3 | unused | Source Four 19° | 575 | |||
| 1ST ELECTRIC | 2 | unused | Source Four 26° | 575 | |||
| 1ST ELECTRIC | 1 | unused | Source Four 36° | 575 | |||
| 1ST ELECTRIC | 26 | unused | Source Four 19° | 575 | |||
| 1ST ELECTRIC | 27 | unused | Source Four 26° | 575 | |||
| 1ST ELECTRIC | 28 | unused | Source Four 36° | 575 | |||
| 7 | unused | LED COIDAK | LED | ||||
| 1ST ELECTRIC | 10 | unused | Source Four 36° | 575 | |||
| 1ST ELECTRIC | 11 | unused | Source Four 36° | 575 | |||
| 1ST ELECTRIC | 16 | unused | S4 PAR | 575 | |||
| 1ST ELECTRIC | 22 | unused | LED COIDAK | LED | |||
| 2ND ELECTRIC | 3 | unused | Source Four 19° | 575 | |||
| 2ND ELECTRIC | 2 | unused | Source Four 26° | 575 | |||
| 2ND ELECTRIC | 1 | unused | Source Four 36° | 575 | |||
| 2ND ELECTRIC | 26 | unused | Source Four 19° | 575 | |||
| 2ND ELECTRIC | 27 | unused | Source Four 26° | 575 | |||
| 2ND ELECTRIC | 28 | unused | Source Four 36° | 575 | |||
| 3RD ELECTRIC | 3 | unused | Source Four 19° | 575 | |||
| 3RD ELECTRIC | 2 | unused | Source Four 26° | 575 | |||
| 3RD ELECTRIC | 1 | unused | Source Four 36° | 575 | |||
| 3RD ELECTRIC | 26 | unused | Source Four 19° | 575 | |||
| 3RD ELECTRIC | 27 | unused | Source Four 26° | 575 | |||
| 3RD ELECTRIC | 28 | unused | Source Four 36° | 575 | |||
| 2ND ELECTRIC | 9 | unused | Source Four 26° | 575 | |||
| 2ND ELECTRIC | 14 | unused | Source Four 26° | 575 | |||
| 2ND ELECTRIC | 20 | unused | Source Four 26° | 575 | |||
| 3RD ELECTRIC | 6 | unused | S4 PAR | 575 | |||
| 3RD ELECTRIC | 7 | unused | LED COIDAK | LED | |||
| 3RD ELECTRIC | 8 | unused | S4 PAR | 575 | |||
| 3RD ELECTRIC | 9 | unused | Source Four 26° | 575 | |||
| 3RD ELECTRIC | 13 | unused | S4 PAR | 575 | |||
| 3RD ELECTRIC | 14 | unused | Source Four 26° | 575 | |||
| 3RD ELECTRIC | 15 | unused | LED COIDAK | LED | |||
| 3RD ELECTRIC | 16 | unused | S4 PAR | 575 | |||
| 3RD ELECTRIC | 20 | unused | Source Four 26° | 575 | |||
| 3RD ELECTRIC | 21 | unused | S4 PAR | 575 | |||
| 3RD ELECTRIC | 22 | unused | LED COIDAK | LED | |||
| 3RD ELECTRIC | 23 | unused | S4 PAR | 575 | |||
| MID CATWALK | unused | Altman 6×12 | 750 |
